Control One AW


2-Way, 100mm (4”) All-Weather Speaker

Product Actions
Take great audio performance throughout your house – and even outside.

Control One AW is the original rugged, compact monitor loudspeaker that crams more than 60 years of JBL expertise into an unobtrusive, all-weather package. Available as pairs in white, Control One AWs let you enjoy the full impact of your favourite music or movies in all your favourite places, indoors or out.


General Specifications

Wall-Mount Capable Yes
Type All-Weather Speakers
Finish White
Grille Color White
Series Control Series

Audio Specifications

Frequency Response 80Hz-20kHz (-3dB)
Power Handling (Peak) 200W
Nominal Impedance 8 Ohms
Power Handling (Recommended) 50W
Sensitivity (2.83V@1m) 87dB
Maximum Recommended Amplifier Power 100W

Speaker Specifications

Low-Frequency Transducer 4" (100mm), magnetically shielded
High-Frequncy Transducer 1/2" (12mm) titanium-laminate, magnetically shielded


Depth (mm) 140
Height (in) 9
Depth (in) 5-1/2
Weight (kg) 2
Height (mm) 229
Width (mm) 156
Width (in) 6-1/8
Weight (lb) 4.3

Control and Connection Specifications

Connector Type Direct Wiring
Click here for a complete list of all specs for this product

Spec Sheet (EN)

709 KB

Spec Sheet (EN)

708 KB
  • 2 Control One AW speakers
  • 2 rotatable wall-mount brackets (including bar wrench and backup cords)
  • Owner’s manual

Search Result For ""

Control One AW is rated 4.5 out of 5 by 4.
Rated 5 out of 5 by from Excellent product.... The speakers were a fantastic purchase decision and the sound is phenomenal!
Date published: 2016-06-12
Rated 5 out of 5 by from Surprising Sound - Outdoor Ready! These little speakers have great JBL sound quality and are perfect for outdoor use. The brackets make it easy to mount them in different areas; I think I'll grab another set of these for the garage. I think I was surprised initially at the quality of these speakers, let's hope they last.
Date published: 2016-06-03
Rated 4 out of 5 by from Great value Easy outdoor mounting. Outstanding sound. Lows and mids impressive for this price point.
Date published: 2016-06-03
Rated 4 out of 5 by from Sound great so far I have been thinking about replacing my 15+ year-old no-name outdoor speakers for a long time and finally did. These are nice speakers with better bass and much more clear than their predecessors. I am NOT an audiophile, but I've found JBL to be a great balance between price, sound and durability. We'll see if these live up to my expectations as time goes on, but so far so good. I have these out in my screen room connected to my HTPC via a Russound selector and a small Pyle PCA2 (2x40w) amp. I use a separate amp for each room and have a spare set of Control One speakers I am planning to install in the garage.
Date published: 2016-05-04
  • y_2019, m_1, d_22, h_2
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.9
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_4
  • loc_en_GB, sid_control-oneaw, prod, sort_[SortEntry(order=RATING, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_jbl

I have a bose sa3 amplifier and im thinking on installing these speakers with this amp, the amp specs says 100w per channel, would It! Worry with this speakers?  Regards.

Asked by: Sereio
The CONTROL ONE is rated to safely handle 100W of RMS power. Any amplifier that is rated to drive 100W of power or lower and can safely handle a 8-ohm speaker would work beautifully.
Answered by: Joe G at Customer Service
Date published: 2017-12-02

What's the difference between Control one and Control one AW? Why are their frequency ranges different?

Asked by: Vincentyin
JBL CONTROL ONE Recommended Power Amplifier Range : 10 Watts – 80 Watts Impedance : 8 Ohms Sensitivity : (2.83V @ 1m) / 89dB Frequency Response : 80Hz – 20kHz High-Frequency Driver : 1/2" Titanium-laminate dome, shielded Low-Frequency Driver : 4", Shielded Dimensions : 9" x 6-1/16" x 5-7/16" (H x W x D) (228mm x 155mm 139mm) Weight : 5.2 lb (2.4kg) CONTROL ONE AW Recommended Power Amplifier Range : 100W Impedance : 8 Ohms Sensitivity : (2.83V @ 1m) 87dB/2.83V/1m Frequency Response : 80Hz – 20kHz High-Frequency Driver : 1/2" (12mm) titanium-laminate, magnetically shielded Low-Frequency Driver : 4" (100mm), magnetically shielded Dimensions : 9" x 6-1/8" x 5-1/2" (229mm x 156mm x 140mm) (H x W x D) Weight : 4.3 lb (2.0kg) The CONTROL ONE AW are all-weather speakers, therefore it can be used outdoors.
Answered by: Aj at Customer Service
Date published: 2017-12-02

Are these speakers wireless? I have one JBL wireless speaker. Can I use 2 JBL speakers for stero sound wireless? Streaming?

Asked by: Jenn5
Answered by: sprhnl
Date published: 2017-12-02

Control oneaw speaker are blue tooth speakers?            What about batteries?

Asked by: Kool
The CONTROL ONE AW is not a Bluetooth speaker. This is a passive speaker. This must be connected to an audio/video surround sound receiver in order to function.
Answered by: Joe G at Customer Service
Date published: 2017-12-02
