Studio 690
Studio 690 Top-graded PolyPlass cones - Image

Top-graded PolyPlass cones

Studio 690 High-quality sounding compression drivers - Image

High-quality sounding compression drivers

Studio 690 New, appealing form factor - Image

New, appealing form factor


Studio 690 High-definition imaging Waveguide with high-frequency compression driver - Image

High-definition imaging Waveguide with high-frequency compression driver

Specs & Downloads

Item# JBLS690W


Studio 690

The new JBL Studio 6 speaker system is everything your inner audiophile was hoping for. Complete with advanced PolyPlas cones, powerful acoustics speaker drivers, and fitted with an all-new, high-definition imaging waveguide using a high-frequency compression driver, your home listening experience will never be quite the same.

General Specifications

Dual 8", 2.5-way compression driver floor standing loudspeaker

Dual 8" (203mm) PolyPlas Low-Frequency Woofer

High Definition Imaging (HDI) Waveguide with 1” (25mm) High Frequency Compression Driver

Recommended Amplifier Power
Max 250W
Frequency Response
36Hz – 40kHz
90dB @ 1M, 2.83V
Nominal Impedance
6 Ohms
Crossover Frequencies
600 Hz, 1.7 kHz
Enclosure Type
Bass-Reflex via Rear-Firing Tuned Port
Dimensions (W x D x H)
300 x 350 x 1058mm

What's in The Box?

  • 1 x JBL Studio 690 Floor Standing Loudspeaker
  • 1 x Owner’s Manual
  • 1 x Warranty Card
  • 4 x Carpet Spikes
  • 4 x Feet Pads
