BAR 500
£499.99
0.0 (0)
Write a review
BAR 500 Dolby Atmos® and MultiBeam™ Surround Sound - Image

Dolby Atmos® and MultiBeam™ Surround Sound

Immerse yourself in theater-quality 3D surround sound. Hear extraordinary sound effects from everywhere in the room, without the need for extra surround speakers.

BAR 500 Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™ - Image

Built-In Wi-Fi with AirPlay, Alexa Multi-Room Music and Chromecast built-in™

Get ready to explore. Access over 300 online music streaming services through AirPlay, Alexa MRM and Chromecast built-in™. Enjoy all of your favorite audio content, Internet radio, and podcasts in high definition. The Wi-Fi connection also allows automatic software updates, so you can always enjoy the latest features.

BAR 500 590W output power - Image

590W output power

With 590 watts of total system output power, the JBL Bar 500 transforms your movies, music and games into immersive sound experiences.

Features

BAR 500 10" Wireless subwoofer - Image

10" Wireless subwoofer

Thrilling, precise bass from a mighty 10" wireless subwoofer brings the action to your movies and the emotion to your music.

BAR 500 PureVoice Dialogue Enhancement Technology - Image

PureVoice Dialogue Enhancement Technology

PureVoice technology uses our unique algorithm to optimize voice clarity to ensure you never miss a word of dialogue, even when the surround effects are at their peak.

BAR 500 HDMI eARC with 4K Dolby Vision Passthrough - Image

HDMI eARC with 4K Dolby Vision Passthrough

Enjoy uncompressed Dolby Atmos surround sound through a single HDMI cable thanks to the HDMI eARC connection. The HDMI input connection also offers 4K video quality from a compatible video player or gaming console.

BAR 500 JBL One App - Image

JBL One App

Customize EQ and control all of your compatible speakers with a single convenient app. The JBL One app helps you easily set up the soundbar, personalize settings, and browse the integrated music services to find your new favorite song.

BAR 500 Easy Sound Calibration - Image

Easy Sound Calibration

Every room is different. Our audio calibration feature ensures that the JBL Bar 500 delivers the best 3D surround effects for any interior and room layout.

BAR 500 Works with voice assistant-enabled speakers - Image

Works with voice assistant-enabled speakers

Simply link the JBL Bar 500 with your voice assistant-enabled device and you can instantly ask Alexa, Google Assistant, or Siri to stream all your favorite music to the soundbar.

Specs & Downloads

Item# JBLBAR500PROBLKUK

Description

What's on the menu tonight? Movies, music or gaming? The JBL Bar 500 brings your movies to life with MultiBeam™ and Dolby Atmos® 3D surround sound. While PureVoice technology optimizes voice clarity to ensure you never miss a word. Feel the thrilling bass from the wireless 10" subwoofer. And with AirPlay, Alexa Multi-Room Music (MRM) and Chromecast built-in™, you've got over 300 easy streaming options to choose from, whether you want to dance or you're ready to relax. Whatever you're in the mood for, the JBL Bar 500's got you covered.

General Specifications

Power supply
100 - 240V AC, ~ 50/60Hz
Networked standby power
< 2.0 W
Operating temperature
0°C - 45 °C

Audio Specifications

Total speaker power output (Max @THD 1%)
590W
Soundbar output power (Max @THD 1%)
290W
Subwoofer output power (Max. @THD 1%)
300 W
Soundbar transducer
4x (46x90)mm racetrack drivers, 3x 0.75" (20mm) tweeters
Subwoofer transducer
10” (260mm)
Frequency response
35Hz - 20kHz (-6dB)
Audio inputs
1 Optical, Bluetooth, USB (USB playback is available in US version. For other versions, USB is for Service only.)

Dimensions

Soundbar dimensions (W x H x D)
1017 x 56 x 103.5 mm / 40’’ x 2.2’’ x 4’’
Subwoofer dimensions (W x H x D)
305 x 440.4 x 305 mm / 12" x 17.3" x 12"
Soundbar weight
2.8kg/ 6.2 lbs
Subwoofer weight
10 kg / 22 lbs
Packaging dimensions (W x H x D)
1105 x 370 x 475 mm/ 43.5" x 14.6" x 18.7"
Packaging Weight
16.2 kg / 35.6 lbs

Control and Connection Specifications

USB port
Type A
USB rating
5V DC, 0.5A
Supporting file format
MP3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate
16 - 48 kHz
MP3 bitrate
80 - 320 kpbs
Bluetooth version
5.0
Bluetooth profile
A2DP 1.2, AVRCP 1.5
Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz
Bluetooth transmitter power
<15 dBm (EIRP)
Wi-Fi network
IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range
2412 - 2472 MHz (2.4 GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power
< 20 dBm (EIRP)
5G Wi-Fi transmitter frequency range
5.15 - 5.35GHz, 5.470-5.725GHz, 5.725 - 5.825GHz
5G Wi-Fi transmitter power
5.15-5.25GHz <23dBm, 5.25-5.35GHz & 5.47-5.725GHz <20dBm, 5.725-5.825GHz <14dBm (EIRP)
2.4G wireless transmitter frequency range
2406 - 2474MH
2.4G wireless transmitter power
<10dBm (EIRP)

What's in The Box?

  • 1 x Main Soundbar
  • 1 x Wireless subwoofer
  • Remote control with 2 x batteries
  • Power cords (up to 8pcs depending on region SKUs)
  • 1 x HDMI cable
  • 2 x L-shape wall-mount bracket with screws
  • Quick start guide
  • Safety Instruction and Warranty Card
  • Wall mount template
What's in The Box?

Documents & Downloads

Reviews and Q&A

Customer Reviews

  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 4ms
  • reviews, product
  • bvseo-msg: Unsuccessful GET. status = 'ERROR', msg = 'Not Found.'; Unsuccessful GET. status = 'ERROR', msg = 'Not Found.';

Product Q&A

is that inbuilted amplifier

Asked by: sureshpandiaraj
No, our JBL BAR 500 does not have an inbuilt amplifier.
Answered by: Customer Support
Date published: 2022-11-20
